Description
Four times better visibility thanks to green laser lines
-
Pendulum lock ensures safe transport
-
Easy handling due to single-handed operation and intuitive user interface
-
Line and point mode freely selectable
-
Horizontal and vertical self-levelling up to ±4°
-
Green horizontal and vertical lines for maximal visibility
-
Multifunctional rotating mount for easy alignment of the laser lines around the plumb points
-
Red plumb points for precise transfer application
Technical data
The most important data
Here you will find the most important technical data for your professional Bosch tool at a glance!
Performance data
|
Operating temperature |
-10 – 50 °C |
|
Storage temperature |
-20 – 70 °C |
|
Laser class |
2 |
|
Working range |
15 m |
|
Accuracy |
± 0.3 mm/m |
|
Self-levelling range |
± 4° |
|
Levelling time |
4 s |
|
Dust and splash protection |
IP 54 |
|
Tripod thread |
1/4″, 5/8″ |
|
Colour of laser line |
green |
|
Projection |
2 lines / 2 points |
|
Plumb point accuracy |
± 0.7 mm/m |
Battery and power
|
Power supply |
3 x 1.5 V LR6 (AA) |
Size and weight
|
Weight, approx. |
0.49 kg |
