Bosch GBH 5-40 DCE Combi Hammer SDS MAX 0611264000

Description

The fast all-rounder with Vibration Control

Fastest drilling rate in its class due to 1150 W motor and powerful hammer mechanism
SDS max comfort for easy and fast tool changes with one hand
Vibration Control (10 m/s² for drilling, 8 m/s² for chiselling) ensures convenient working, even in time-intensive applications

Product Highlights

The GBH 5-40 DCE Professional is uniquely designed within Bosch’s SDS max corded rotary hammer category for comfortable handling and reduced user fatigue in extensive applications. Its Vibration Control and lightweight design enable effortless and continuous work in time-intensive tasks. The rotary hammer is also built for durability, featuring robust metal components and an optimised lubrication system. Its strong motor enables the delivery of 8.8 J of impact energy for a fast drilling progress and high material removal rate.

Performance data

Impact rate at rated speed 1,500 – 2,980 bpm
Rated speed 165 – 330 rpm
Additional data
Rated input power 1,150 W
Impact energy (according to EPTA 05/2016) 8.8 J
Weight 6.8 kg
Tool holder SDS max

Drilling range

Drilling dia. concrete, hammer drill bits 12 – 40 mm
Opt. appl. range concrete, hammer drill bits 18 – 32 mm
Drilling dia. concrete, breakthrough drill bits 45 – 55 mm
Drilling diameter in concrete with core cutters 40 – 90 mm

Total vibration values (Hammer drilling in concrete)
Vibration emission value ah 16.2 m/s²
Uncertainty K 1.5 m/s²
Total vibration values (Chiselling in concrete)
Vibration emission value ah 10.5 m/s²
Uncertainty K 1.5 m/s²
Hammer drilling in concrete
Vibration emission value ah 16.2 m/s²
Uncertainty K 1.5 m/s²
Chiselling in concrete
Vibration emission value ah 10.5 m/s²
Uncertainty K 1.5 m/s²

The A-rated noise level of the power tool is typically as follows: Sound pressure level 94 dB(A); Sound power level 105 dB(A). Uncertainty K= 3 dB
